Electrochemical Oxygen Sensor (O2 Sensor) O2-C2 For Oxygen Alarms Atmosphere Analyzers

گواهی
چین ShenzhenYijiajie Electronic Co., Ltd. گواهینامه ها
چین ShenzhenYijiajie Electronic Co., Ltd. گواهینامه ها
چت IM آنلاین در حال حاضر

Electrochemical Oxygen Sensor (O2 Sensor) O2-C2 For Oxygen Alarms Atmosphere Analyzers

Electrochemical Oxygen Sensor (O2 Sensor) O2-C2 For Oxygen Alarms Atmosphere Analyzers
Electrochemical Oxygen Sensor (O2 Sensor) O2-C2 For Oxygen Alarms Atmosphere Analyzers Electrochemical Oxygen Sensor (O2 Sensor) O2-C2 For Oxygen Alarms Atmosphere Analyzers Electrochemical Oxygen Sensor (O2 Sensor) O2-C2 For Oxygen Alarms Atmosphere Analyzers

تصویر بزرگ :  Electrochemical Oxygen Sensor (O2 Sensor) O2-C2 For Oxygen Alarms Atmosphere Analyzers

جزئیات محصول:
Place of Origin: Japan
Model Number: O2-C2
پرداخت:
Minimum Order Quantity: 1PCS
قیمت: قابل مذاکره
Packaging Details: Standard packaging
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, T/T, MoneyGram
Supply Ability: 5000pcs

Electrochemical Oxygen Sensor (O2 Sensor) O2-C2 For Oxygen Alarms Atmosphere Analyzers

شرح
Measurement Range: 0 - 30% Output: 80 - 120μA @ 22°C, 20.9% O2
Response Time t90: < 45s Operating Life: > 24 months
Temperature Range: -30°C to 55°C Pressure Range: 80 to 120kPa
برجسته کردن:

Electrochemical O2 sensor for alarms,Oxygen gas sensor for analyzers,O2-C2 oxygen atmosphere sensor

,

Oxygen gas sensor for analyzers

,

O2-C2 oxygen atmosphere sensor



              Electrochemical Oxygen Sensor (O2 Sensor) O2-C2 for Oxygen Alarms and Atmosphere Analyzers



Product Uses:



The O2 - C2 oxygen sensor is mainly used in oxygen alarms and atmosphere analyzers. It is widely applied in coal mines, steel, petrochemical, medical and other fields, which can be used to detect the oxygen concentration in the environment to ensure safety and the normal operation of related equipment.



Product Features:



Wide Measurement Range: The measurement range is 0 - 30%, which can meet the oxygen detection needs of most general - purpose environments.

Long Service Life: The operating life is more than 24 months, reducing the frequency of replacement and maintenance costs.

Fast Response: The response time t90 is less than 45 seconds (from 20.9% to 0% O2), which can quickly reflect the change of oxygen concentration, and is conducive to timely monitoring and processing of oxygen - related emergencies.

Good Linearity: The linearity is - 0.6% O2 deviation @ 10% O2, which can provide relatively accurate measurement results and ensure the reliability of the measurement data.

Strong Environmental Adaptability: It can work in the temperature range of - 30°C to 55°C, the pressure range of 80 to 120kPa, and the humidity range of 5 - 95%RH (continuous), 0 - 99%RH (short - term), and has good adaptability to different environmental conditions.

Portable and Light - weight: With a size of Φ20.3×23mm and a weight of less than 18g, it is easy to install and use, and is suitable for various portable detection devices.

Lead - free Design: It is a lead - free electrochemical sensor, which has a longer service life than lead - based sensors, reduces the risk of sensor leakage, and is more environmentally friendly.

Capillary Flow Control: Using capillary flow control, unlike partial - pressure oxygen sensors, it has good pressure and temperature dependence, and is an excellent choice for safety - related applications.





Measurement Range 0 - 30%
Output 80 - 120μA @ 22°C, 20.9% O2
Response Time t90 < 45s (from 20.9% to 0% O2)
Operating Life > 24 months
Temperature Range -30°C to 55°C
Pressure Range 80 to 120kPa
Humidity Range 5 - 95%RH (continuous), 0 - 99%RH (short - term)
Weight < 18g
Storage Period 6 months @ 3 to 20°C (store in sealed pot, open - circuit)
Load Resistor 47 to 100Ω
Size Φ20.3×23mm



Electrochemical Oxygen Sensor (O2 Sensor) O2-C2 For Oxygen Alarms Atmosphere Analyzers 0
