281637 282049 282051 Flow sensor For Medical ventilators

281637 282049 282051 Flow sensor For Medical ventilators
281637 282049 282051 Flow sensor For Medical ventilators 281637 282049 282051 Flow sensor For Medical ventilators 281637 282049 282051 Flow sensor For Medical ventilators 281637 282049 282051 Flow sensor For Medical ventilators 281637 282049 282051 Flow sensor For Medical ventilators 281637 282049 282051 Flow sensor For Medical ventilators 281637 282049 282051 Flow sensor For Medical ventilators

تصویر بزرگ :  281637 282049 282051 Flow sensor For Medical ventilators

جزئیات محصول:
محل منبع: ایالات متحده آمریکا
شماره مدل: 281637 282049 282051
پرداخت:
مقدار حداقل تعداد سفارش: 1 عدد
قیمت: قابل مذاکره
جزئیات بسته بندی: بسته بندی استاندارد
زمان تحویل: 5-8 روز کاری
شرایط پرداخت: L/C ، D/A ، D/P ، T/T ، Western Union ، MoneyGram
قابلیت ارائه: 5000 قطعه

281637 282049 282051 Flow sensor For Medical ventilators

شرح
دامنه جریان: 0 تا 180 لیتر در دقیقه (کوتاه مدت 260 لیتر در دقیقه) فضای مرده: <11 میلی لیتر (عملکردی)
مقاومت: <0.027 cmh2o/(l/min) بیش از محدوده جریان کامل (-180 لیتر در دقیقه تا 180 لیتر در دقیقه) درجه حرارت: کار: -20 درجه سانتیگراد تا 50 درجه سانتیگراد (-4 درجه فارنهایت تا 122 درجه فارنهایت)
برجسته کردن:

medical ventilator flow sensor,air flow sensor for ventilators,medical air flow sensor with warranty

,

air flow sensor for ventilators

,

medical air flow sensor with warranty



                                           281637 282049 282051 Flow sensor For Medical ventilators





Product Overview:

The 281637 is a compact, industrial-grade gas sensor designed for reliable detection of specific target gases (confirm target gas with manufacturer, e.g., carbon monoxide, methane, volatile organic compounds, or oxygen). It adopts semiconductor (metal oxide) or electrochemical sensing technology (depending on target gas) to deliver fast response, low power consumption, and stable long-term performance. Typical applications include industrial safety monitoring (e.g., factory leak detection), indoor air quality (IAQ) management, smart home safety systems, and portable gas detectors.



No.

Component/Parameter Category

Description

Specification/Details

Material

Remarks

1 Connector Ventilator side OD15 PSU -
2 Tubing - - PVC -
3 Connectors for Tubing Differential pressure measurement - PSU -
4 Direction Index - - - -
5 Individual Serial Number - - - -
6 Connector Patient side OD22/ID15 PSU -
7 Flap - - PET -
- Technical Performance Flow range 0 to 180 l/min (short term: 260 l/min) - -
- Technical Performance Dead space < 11 ml (functional) - -
- Technical Performance Resistance < 0.027 cmH₂O/(l/min) over the complete flow range (-180 l/min to 180 l/min) - -
- Technical Performance Weight - Approx. 14 g (without tubes)
- 68 g (with 188 cm tubes)
- 89 g (with 260 cm tubes)
- 110 g (with 330 cm tubes)
- -
- Material Compliance Material standards 1. Complies with ISO 10993-1:2009 (biocompatibility)
2. Complies with Directive 2011/65/EU (RoHS)
3. No natural rubber latex, DEHP, or BPA
- Ensures safety for medical use
- Accuracy (Calibrated Flow Sensor) Volume-related parameters (HAMILTON ventilators) - HAMILTON-C1/T1/MR1/C2/C3/C6: ± 10% or ± 10 ml (whichever is greater)
- HAMILTON-G5/S1: ± 15% or ± 20 ml (whichever is greater)




281637 282049 282051 Flow sensor For Medical ventilators 0
